| Product Model |
KFXRS-19II/C4 |
| Power Supply |
380V 3N~ 50Hz |
| Electrostatic Protection Level |
I |
| Waterproof Grade |
IPX4 |
| Rated Heating Capacity |
19400W |
| Rated Consumption Power |
4260W |
| Rated Heating Working Current |
7.6A |
| Max. Consumption Power |
6400W |
| Max. Working Current |
11.5A |
| Rated Outlet Water Temperature |
55℃ |
| Max. Outlet Water Temperature |
60℃ |
| Rated Water Output |
415L/h |
| Circulating Water Flow |
3.34m³/h |
| Water Side Pressure Loss |
45kPa |
| High/Low Side Max. Working Pressure |
4.2MPa/4.2MPa |
| Exhaust/Suction Side Max. Working Pressure |
4.2MPa/1.5MPa |
| Evaporator Max. Bearing Pressure |
4.2MPa |
| Pipe Diameter of Circulating Water |
DN32 |
| Connector of Pipe of Circulating Water |
1¼” |
| Noise |
≤64dB(A) |
| Refrigerant/Charging Amount |
R410A/2.9kg |
| Outer Dimension |
800 x800 x1040 (mm) |
| Net Weight |
165kg |
