Machine model:KFXRS-45II
Rated heating capacity:45000W
Maximum power consumption:15750W
Maximum operating current:30A
Maximum outlet temperature:60℃
Circulating water flow:8.5m³/h
Circulating water pipe diameter:DN40
Noise:≤64dB(A)
net weight:450kg
power supply:380V3N~50Hz
Rated power consumption:10150W
Rated working current:20A
Rated water temperature:55℃
Nominal water production:1000L/h
Water side pressure loss:70kPa
Circulating water pipe diameter/pipe connection:1½” Coupling
Flush volume:R410A (3.4×2)kg
External dimensions:1750*950*1240（mm）
