| Product Model |
KFXRS-11 I BM/C1 |
| Waterproof Grade |
IPX4 |
| Rated Heating Capacity |
11000W |
| Rated Consuming Power |
2290W |
| Rated Working Current |
10.4A |
| Maximum Consuming Power |
3600W |
| Maximum Working Current |
17A |
| Rated Outlet Water Temperature |
55℃ |
| Highest Outlet Water Temperature |
60℃ |
| Nominal Output Water Volume |
235L/h |
| Circular Water Flow |
1.89m³/h |
| Water Side Pressure Loss |
25kPa |
| High/Low Pressure Side Highest Working Pressure |
4.5MPa/3.0MPa |
| Exhaust/Intake Highest Working Pressure |
4.5MPa/1.5MPa |
| Evaporator Highest Bearing Pressure |
4.5MPa |
| Circular Water Pipe Diameter |
DN25 |
| Circular Water Pipe Connector |
1”内丝 |
| Noise |
≤56dB(A) |
| Refrigerant/Charged Volume |
R410A/2.05kg |
| Outer Dimension |
950 x 350 x 850 ( mm ) |
| Net Weight |
78kg |
